PRODUCT SPECS

LEDs Brands: Osram
Drivers Brands: Osram Optotronic IP67 2DIM
Coating: Special Conformal Coating for LEDs
Spectrum: Full Spectrum 4K
PPF: 1700μmol/s
Efficacy: 2.7μmol/JInput Voltage: AC 220-240V 50/60HZ
Output Power: 880W
Power Factor: ≥ 90%
Dimensions: 120x72x134mm
Amp: 4
Dimming: Knob (0-%25-%50-%75-%100) or 0-10V Signal (with Luxumol Led Master Controller max:25 Luxumol Pro Led 630)
Beam Angle: 120 °
Mounting Height: ≥ 6'' Above Canopy
Operation Temperature: -40°C / 55°C
Operation Humidity: 10%-95% RH
Storage Temperature: -50°C / 80°C
Storage Humidity:
10%-95% RH
Warranty Time: 5 years
(Watts Value are typical expected values. Tolerance allow +/- 10%range on flux and power consumption.)

CAUTION

➢ The operating voltage range of this device is AC 220V-240V. Do not operate outside this voltage range.
➢ If one or more products (max: 25 pcs) will be controlled with a luxumol led master controller, the dim potency position on the device should be EXT.
➢ This product is passively cooled design, so do not moving components and do not try to open or disassemble the fixture, unless it contain no service parts inside.
➢ Always adhere to the local rules and regulations when you use it.
➢ Gloves and safety glasses should be worn during installation and maintenance, and it should be ensured that the electrical power is cut off.
➢ Since the temperature will rise when the luminaire is open, it should not be touched.
➢ Make sure the product is turned off before touching it, and allow it to cool for at least 10 minutes before touching it after it is turned off.
➢ Since the product contains special LED diodes, never interfere, it may damage the coating and the LEDs on it.
➢ Do not use when LED bars, drivers, power cord or plug are faulty or damaged.
➢ Keep this product away from children.
